Pollo PLC-5504H1PM
₨12,650.00
04 CHANNEL NVR
- 04 channel Input
- 5MP Resolution
- ONVIF
- Output HDMI & VGA
- 264/H.265+
- 1 SATA Interface Up-to 6TB, Smart Search
Specifications
| Model | PLC-5504H1/PM |
|---|---|
| System | Embedded Linux |
| Video Network Input | 4 CH IPC input |
| Network Input Resolution | 6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF |
| Video Output | HDMI × 1: 1920 × 1080 / 1280 × 1024/1024 × 768 VGA: 1920 × 1080 / 1280 × 1024/ 1024 × 768 HDMI and VGA output the same video source |
| Compression | H.265S / H.265+ /H.265 /H.264 |
| Network Input | 4 CH IPC audio input |
| Compression | G.711(U/A) |
| Record Stream | Dual stream recording |
| Resolution | 6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF |
| Frame Rate | 6MP@20fps (NTSC/PAL); 5MP or lower@30fps/25fps (NTSC/PAL) |
| Simultaneous Playback | Max. 4 CH |
| Play Back Search | Time slice / time / event / tag /smart search |
| Play Back Smart Search | Highlighted colour to display the camera record in a certain period of time, different colours refer to different record events |
| Play Back Function | Play, pause, FF, FB, digital zoom, etc. |
| Live View/ Playback | 1CH 6MP; 4CH 720P |
| Mode | Manual, sensor, motion, exception, smart events |
| Input | Support IPC alarm input |
| Output | Support IPC alarm output |
| Triggering | Record, snapshot, buzzer, pre-set, e-mail, etc. |
| Interface | RJ 45 100Mbps × 1 |
| Network Protocol | TCP / IP, I v4, I v6, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, 802.1x, RTSP, SNMP, ONVIF, etc. |
| Incoming Bandwidth | 32 Mbps |
| Outgoing Bandwidth | 32 Mbps |
| Client Connection | Max. 10 users’ access |
| Plate Recognition | Yes |
| Mobile Device | iOS, Android |
| Storage | SATA2.0 × 1, max 8T |
| Local Backup | U disk, USB mobile HDD |
| Network Backup | Yes |
| USB | USB 2.0 × 2 |
| Power Supply | DC 12V/1.5A |
| Consumption | < 6W (without HDD) |
| Dimensions (mm) | 255 × 222 × 42 (W × D × H) |
| Working Environment | -10 ～ 50 ℃，10% ～ 90% humidity |
| Certificate | CE, FCC |
| Environmental Protection | Complies with Directive EU RoHS, REACH and WEEE |
